Programmable Type Salt Spray Testing Machine With PLC Touch Screen Controller
This programmable salt spray testing machine is designed to evaluate the corrosive resistance of products with surface treatments including paint, electroplating, inorganic and organic films, anode handling, and anti-rust oil applications.
Technical Parameters
| Model | ZL-6001B (108L) | ZL-6001B (270L) | ZL-6001B (480L) |
| Inside Box Size (cm) | 60*45*40 | 90*60*50 | 120*80*50 |
| Outside Box Size (cm) | 107*60*118 | 141*88*128 | 190*110*140 |
| Testing Room Capacity | 108L | 270L | 480L |
| Brine Tank Capacity | 15L | 25L | 40L |
| Power | AC220V 1Φ 10A | AC220V 1Φ 15A | AC220V 1Φ 20A |
Temperature Specifications
Testing Room Temperature: Salt test (NSS ACSS) 35℃±1℃ / Corrosion Test (CASS) 50℃±1℃
Pressure Barrel Temperature: Salt test (NSS ACSS) 47℃±1℃ / Corrosion Test (CASS) 63℃±1℃
Brine Temperature: 35℃±1℃ / 50℃±1℃
Performance Specifications
Salt Concentration: Sodium chloride 5% or 5% sodium chloride with 0.26g per liter of copper chloride (CuCl₂·2H₂O)
Air Pressure: 1.00±0.01kgf/cm²
Spray Volume: 1.0~2.0ml/80cm²/h (average after minimum 16 hours operation)
Testing Room Relative Humidity: 85% above
PH Range: 6.5~7.2 / 3.0~3.2
Spray Form: Programmable spray (including continuous and intermittent spray)
Compliance Standards
- GB/T 2423.17-1993 salt spray test
- GB/T 2423.18-2000 salt spray test
- GB/T 10125-1997 salt spray test
- ASTM B117-97 salt spray test
- JIS H8502 salt spray test
- IEC68-2-11 salt spray test
- IEC68-2-52 1996 salt spray test
- GB.10587-89 salt spray test
- CNS.4158 salt spray test
- CNS.4159 CASS Accelerated acetic acid copper salt spray test
- GB/T 12967.3-91 CASS Accelerated acetic acid copper salt spray test
Heating System
Utilizes steam direct heating method for rapid heating and reduced standby time. Automatically switches to constant temperature state when specified temperature is reached, providing precise temperature control and low power consumption. Features pure titanium heating tubes resistant to acid and alkali corrosion for extended service life.
